Frontier LP7700 - Page 657

3/4
5. Operation sequence
55110
55110
Paper advance operation
Paper magazine A2
Goes to Step 10.
9. The paper passes through the paper end sensor.
When paper end sensors A/B/C cannot detect the paper
10. The paper passes through the paper loading sensor.
When paper loading sensors A/A2/B/C cannot detect the paper
• ☞ No. 06012-00002
Paper did not load. Paper Magazine A
•
☞No. 06201-00002
Paper did not load. Paper Magazine A
•
☞No. 06195-00002
Paper did not load. Paper Magazine A2
•
☞No. 06013-00002
Paper did not load. Paper Magazine B
•
☞No. 06012-00002
Could not load the paper. Paper Magazine C
Paper magazines A, B and C
Goes to Step 12.
Paper magazine A2
Goes to Step 11.
11. The pressure of the advance roller A2 is released.
• Pressure release motor A2: ON
When the pressure release motor does not operate
• ☞ No. 06199-00002
Pressure Release Motor A2 operation error.
12. Condition is confirmed.
Loading for the first time after turning on the power supply or open/close the printer door
Goes to Step 13.
Paper end sensor A Paper end sensor B
•
☞No. 06012-00001
Paper did not load. Paper Magazine A
•
☞No. 06201-00001
Paper did not load. Paper Magazine A
•
☞No. 06227-00001
Paper did not load. Paper Magazine A
•
☞No. 06231-00001
Paper did not load. Paper Magazine A
•
☞No. 06013-00001
Paper did not load. Paper Magazine B
•
☞No. 06112-00001
Could not load the paper. Paper Magazine C
•
☞No. 06013-00001
Paper did not load. Paper Magazine B
•
☞No. 06228-00001
Paper did not load. Paper Magazine B
Paper end sensor C
• ☞No. 06112-00001
Could not load the paper. Paper Magazine C
• ☞No. 06229-00001
Could not load the paper. Paper Magazine C
