5. Operation sequence
55500
4/6
55500
Paper advance operation
7. Arm unit 2 (left) moves to paper receiving position of paper advance unit 1.
• Lane select motor (left): ON/OFF
If land select sensor (left) does not turn LIGHT
• ☞ No. 06140-00002
Lane Select Motor (Left) operation error.
8. Paper is advanced to arm unit 2 (left).
9. Arm unit 2 (left) pressures the paper.
• Paper advance pressure change motor (left): ON (pressured)/OFF
If the paper advance pressure change sensor (left) does not turn DARK
• ☞ No. 06142-00001
Paper Advance Pressure Change Motor (Left) operation error.
G069843
G069844
