5. Operation sequence
55530
2/4
55530
Paper advance operation
• Paper advance arm motors (right) (left): ON/OFF
If the arm sensors (right) (left) do not turn DARK
• ☞ No. 06138-00001
Paper Advance Arm Motor (Left) operation error.
•
☞No. 06139-00001
Paper Advance Arm Motor (Right) operation error.
3. The paper is advanced to arm units 2 (right) (left).
4. Arm units 2 (right) (left) pressure the paper.
• Paper advance pressure change motors (right) (left): ON (pressured)/OFF
If the paper advance pressure change sensors (right) (left) do not turn DARK
• ☞ No. 06142-00001
Paper Advance Pressure Change Motor (Left) operation error.
•
☞No. 06143-00001
Paper Advance Pressure Change Motor (Right) operation error.
