Frontier LP7700 - Page 744

5. Operation sequence
56620
3/3
56620
Colorimeter unit operation
The correction value is within 2 times of the value at Initial
Setup or paper specification registration setup.
Error
☞No. 06203-#2006
Setup error.
YES
All three colors of C, M and Y have the similar tendency.
NO
YES
Error ☞No. 06204-#3003
Setup error.
Requires plus correction. (Print density has been
decreased.)
YES
Attention message ☞No. 01029The measurement failed.
Measure it again.
NO
Correction value registration
NO
The correction value is below 3 key of the previous value.
NO
Error
☞No. 06203-#2005
Setup error.
YES
All three colors of C, M and Y have the similar tendency.
NO
YES
Error ☞No. 06204-#3002
Setup error.
Requires plus correction. (Print density has been
decreased.)
YES
Attention message ☞No. 01029The measurement failed.
Measure it again.
NO
A
A
