6. Electrical parts
63311-5
63311-5
Positions of electrical parts (Processor section)
*1. For details about processor section fan operation specification, see ☞63321.
4 STB2 processing solution float switch FS4
STB2 refilling water level
5 STB3 processing solution float switch FS5
STB3 refilling water level
6 STB4 processing solution float switch FS6
STB4 refilling water level
STB4 processing solution level
STB4 safety thermostat
7 CD effluent float switch FS7
8 BF effluent float switch FS8 Option
9 STB effluent float switch FS9
11 CD thermosensor TH1
12 BF thermosensor TH2
13 STB thermosensor TH3
14 Interlock switch (Processor top cover) LS4
15 Rack stopper sensor LS14
16 Power supply cooling fan 1 FAN14 Blowing
*1
17 Power supply cooling fan 2 FAN18 Exhaust
*1
18 Exhaust fan FAN20 Exhaust
*1
19 Tank cooling fan 1 FAN22 Intake
*1
20 Tank cooling fan 2 FAN23 Intake
*1
21 Tank cooling fan 3 FAN24 Intake
*1
22 Tank cooling fan 4 FAN25 Exhaust
*1
23 Drive motor M3
24 CD1 circulation pump P1
25 BF1 circulation pump P3
26 STB1 circulation pump P5
27 STB2 circulation pump P6
28 STB3 circulation pump P7
29 STB4 circulation pump P8
30 CD heater H1
31 BF heater H2
32 STB heater H3
33 Hour meter HM1
34 CD digital flowmeter FLS1 Option
35 Earth leakage circuit breaker 1 NFB2 See
☞4203.
36 Earth leakage circuit breaker 2 NFB3
37 Earth leakage circuit breaker 3 NFB4
38 Terminal strip 1 TA1
39 Terminal strip 2 TA2
40 Transformer TR1
No. Name Symbol Remarks
