6. Electrical parts
66100
2/2
66100
Description of PCB (printer section)
!
!!
! Reference
!
!!
! Adjustments and precautions for PCB replacement
• Do not change each volume that has already been adjusted by the manufacturer before shipment.
!
!!
! Unused connector
!
!!
! Component parts table
Fuse
Layout diagram Symptom due to the poor connection of
wiring
Symptoms of fuse blowout
☞63000 ☞4202 -
Power supply Connector No. Purpose Remarks
Printer power supply 1 CN2, CN52 Unused
Printer power supply 2 None
Printer power supply 3 None
Laser power supply None
Printer power supply 4 None
Printer power supply 5 CN2, CN52 Unused
Power supply Fuse No. Purpose Remarks
Printer power supply 1 F1 AC 200 V power
supply protection
Cannot be replaced.
Printer power supply 2 F1 AC 200 V power
supply protection
Printer power supply 3 F1 AC 200 V power
supply protection
Laser power supply F1 AC 200 V power
supply protection
Printer power supply 4 F1 AC 200 V power
supply protection
Printer power supply 5 F1 AC 200 V power
supply protection
