Hard disk drives / solid state drives
7.2.2 Installing 2.5-inch HDD / SSD modules
7.2.2.1 Preliminary steps
Ê Locate the correct drive bay as described in section "Mounting order for 2.5-
inch HDDs / SSDs" on page 122.
2.5-inch HDDs / SSDs
HDD bay RAID Manager #
1 [0]
2 [1]
3 [2]
4 [3]
5 [4]
6 [5]
7 [6]
8 [7]
9 [8]
10 [9]
11 [10]
12 [11]
13 [12]
14 [13]
15 [14]
16 [15]
Table 7: HDD naming scheme
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
