13.2.3 Replacing the front VGA connector
13.2.3.1 Preliminary steps
Ê "Disabling or suspending BitLocker functionality" on page 67
Ê "Locating the defective server" on page 49
Ê "Shutting down the server" on page 51
Ê "Disconnecting power cords" on page 52
Ê "Getting access to the component" on page 53
Ê "Removing the fan box" on page 168
13.2.3.2 Removing the front panel module
Ê "Removing the front panel module" on page 316
13.2.3.3 Removing the front VGA connector
Ê "Removing the front VGA connector" on page 321.
13.2.3.4 Installing the new front VGA connector
Ê Install the new front VGA connector as described in section "Installing the
front VGA connector" on page 317.
13.2.3.5 Re-installing the front panel module
Ê "Installing the front panel module" on page 313.
13.2.3.6 Concluding steps
Ê "Installing the fan box" on page 171
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Socket screw driver (5 mm)
Wrench key for UNC #4-40 hexagon bolts
