RX2520 M1
Upgrade and Maintenance Manual 303
Accessible drives
12.11.3 Removing a LTO drive out of the cage
Figure 198: Removing the cover plate
Ê Remove the cover plate from the drive cage.
Figure 199: Removing the screws
