Ê Remove the ID card and save the ID-card with the server.
15.3.2 2.5-inch HDD versions
Figure 258: Cage numbers for HDDs and front panel
15.3.2.1 Configuration 2 to configuration 4
I The configuration 2 must include a SAS controller. Otherwise you must
install a SAS controller as described in section "Installing the SAS RAID
controller" on page 191.
Figure 259: 4x 2.5-inch version
Figure 260: 8x 2.5-inch HDD version
