Fujitsu PRIMERGY RX2520 M1 - Installing a HDD Cage

RX2520 M1 Upgrade and Maintenance Manual 159
Hard disk drives / solid state drives
Figure 67: Removing the 4x 2.5-inch HDD SAS backplane
Ê Remove the screw.
Ê Push the HDD cage out.
7.5.2 Installing a HDD cage
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
