13.2.2.1 Preliminary steps
Ê "Disabling or suspending BitLocker functionality" on page 67
Ê "Locating the defective server" on page 49
Ê "Shutting down the server" on page 51
Ê "Disconnecting power cords" on page 52
Ê "Getting access to the component" on page 53
Ê "Removing the fan box" on page 168
13.2.2.2 Removing the front VGA cable
Figure 213: Disconnecting the front VGA cable
Ê Remove the front VGA cable from the system board.
Ê "Removing the front panel module" on page 313
Tools: Socket screw driver (5 mm)
Wrench key for UNC #4-40 hexagon bolts
