RX2520 M1 Upgrade and Maintenance Manual 151
Hard disk drives / solid state drives
7.4.2.4 Concluding steps
Ê "Installing the fan box" on page 171
Ê "Reassembling" on page 59
Ê "Installing 2.5-inch HDD / SSD modules" on page 127
Ê "Connecting the server to the power source" on page 64
Ê "Switching on the server" on page 66
Ê "Enabling BitLocker functionality" on page 93
7.4.3 Replacing the 12x 3.5 inch HDD backplane
7.4.3.1 Preliminary steps
Ê "Locating the defective server" on page 49
Ê "Disabling or suspending BitLocker functionality" on page 67
Ê "Shutting down the server" on page 51
Ê "Disconnecting power cords" on page 52
Ê Remove all HDD modules from the server as described in section
"Removing 3.5-inch HDD modules" on page 138.
V CAUTION!
Ensure that all hard disk drives are uniquely identified so that you can
reinsert them into their original bays after replacing the HDD
backplane.
Ê "Getting access to the component" on page 53
Ê "Removing the fan box" on page 168
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
