Ê Switch on the ID indicator on the front and rear connector panels of the
server as described in section "Locating the defective server" on page 49.
4.3 Disconnecting power cords
Removing the server from the mains
I If there are installed two power supplies remove both power cords.
Figure 2: Removing the power cord from the PSU cable clamp
Ê Open on the locking lever on the PSU cable clamp (1).
Ê Disconnect the power cord from the PSU and remove it from the cable tie
(2).
