12.1 Basic informations
Mounting order for accessible drives in the front panel cage
PRIMERGY RX2520 M1 server offers one 5.25-inch accessible drive bays for
optical disk drives and backup drives:
Figure 141: Accessible drives in front panel cage
Mounting order for accessible drives in the HDD bays
PRIMERGY RX2520 M1 server offers several possibilities to install tape drives:
Figure 142: Accessible drive (LTO) in HDD bays for 2.5-in HDD version
No. Accessible drive Bay Max. no.
1 Local Service Display 3.5-inch bay 1
2 Optical disk drive 5.25 inch bay 1
