RX2520 M1 Upgrade and Maintenance Manual 267
Accessible drives
Figure 157: Installing the ODD
Ê Run the SATA and power cables through the ODD bay opening as shown.
Ê Connect the power cable to the ODD (1).
Ê Connect the SATA cable to the ODD (2).
12.5.1.5 Concluding steps
Ê "Installing the fan box" on page 171
Ê "Reassembling" on page 59
Ê "Connecting the server to the power source" on page 64
Ê "Enabling BitLocker functionality" on page 93
12.5.2 Removing the optical disc drive (ODD)
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
