262 Upgrade and Maintenance Manual
RX2520 M1
Accessible drives
12.4.1 Preliminary steps
Ê "Disabling or suspending BitLocker functionality" on page 67
Ê "Shutting down the server" on page 51
Ê "Disconnecting power cords" on page 52
Ê "Getting access to the component" on page 53
Ê "Removing the fan box" on page 168
12.4.2 Removing the defective LSD module
Ê "Removing the LSD module" on page 259
12.4.3 Installing the new LSD module
Ê "Installing a LSD module" on page 257
12.4.4 Concluding steps
Ê "Installing the fan box" on page 171
Ê "Reassembling" on page 59
Ê "Connecting the server to the power source" on page 64
Ê "Enabling BitLocker functionality" on page 93
12.5 Optical disk drive (ODD) for 2.5-inch version
12.5.1 Installing the optical disk drive (ODD)
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH0 / (+) No. 0 screw driver
