114 Upgrade and Maintenance Manual RX2520 M1
Power supply units
6.6.2 Disconnecting cables
Figure 22: Disconnecting cables from the power backplane
Ê Remove the cables from the power backplane.
6.6.3 Removing the power backplane
Figure 23: Removing the power backplane (A)
Ê Unlock the locking mechanism of the power backplane.
