RX2520 M1
Upgrade and Maintenance Manual 241
Processors
11.3.2.1 Installing the protective cover
Figure 131: Attaching the protective socket cover
Ê Carefully lower the protective socket cover onto the processor socket in a
vertical motion until it snaps in place.
I Notice the coding!
Figure 132: Closing the load plate
Ê Close the load plate of the processor.
