376 Upgrade and Maintenance Manual
RX2520 M1
Conversion configurations
15.2.1.2 Removing the front cover
Figure 251: Removing the rack front cover (A)
Ê Disengage all tabs of the front cover.
Figure 252: Removing the rack front cover (B)
Ê Carefully remove the front cover. Do not damage the hooks of the front
cover.
15.2.1.3 Concluding steps
Ê "Reassembling" on page 59
