168 Upgrade and Maintenance Manual
RX2520 M1
System fan
8.3.2 Removing the fan box
Figure 72: Removing a fan module
Ê Take the two system fans by the green touch points and lift the system fans
out of the fan box.
FAN2
FAN4
