RX2520 M1
Upgrade and Maintenance Manual 421
Appendix
17.3.3 Connectors and indicators on the front panel
17.3.3.1 Front panel connectors (2.5-inch HDD version)
Figure 294: Front panel connectors
1 Front VGA 2 USB
