Ê For more information about the cabling see "Configuration 7" on page 407.
Ê "Installing the fan box" on page 171
Ê "Reassembling" on page 59
Ê Connect all external cables.
Ê "Connecting the server to the power source" on page 64
Ê Update your server’s chassis information on the Chassis ID EPROM
integrated into the front panel board. For further information on how to obtain
and use the ChassisId_Prom Tool, refer to section "Using the Chassis ID
Prom Tool" on page 97.
Ê "Enabling BitLocker functionality" on page 93
15.3.2.5 Configuration 2 to configuration 3
I The configuration 2 must include a SAS controller. Otherwise you must
install a SAS controller as described in section "Installing the SAS RAID
controller" on page 191.
Figure 263: 4x 2.5-inch version
Figure 264: 4x 2.5-inch version + LTO
