12.5.2.1 Preliminary steps
Ê Ask the system administrator to eject all remaining backup or optical media
from the backup or optical disk drive before removing it from the server.
Ê "Disabling or suspending BitLocker functionality" on page 67
Ê "Shutting down the server" on page 51
Ê "Disconnecting power cords" on page 52
Ê "Getting access to the component" on page 53
Ê "Removing the fan box" on page 168
12.5.2.2 Removing the ODD
Figure 158: Removing the ODD (A)
Ê Disconnect the SATA cable (1) and the power cable (2).
Ê Pull the locking latch upward to unlock the ODD.
Ê Push the ODD out of the bay.
Tools: Torx Plus 6 screw driver
