17 Appendix
17.1 Mechanical overview
17.1.1 Server front
Figure 286: Server front side 2.5-inch version
Figure 287: Server front side 3.5-inch version (8x 3.5-inch version)
Pos. Component
1 LSD module
2 Front panel module
3 Optical disk drive
4
Space for hard disc drives and backup drives (depending on the
configuration)
