Fujitsu PRIMERGY RX2520 M1 - Re-Installing the Front Panel Module

318 Upgrade and Maintenance Manual RX2520 M1
Front panel and external connectors
Figure 211: Mounting the front VGA connector
Ê Insert the front VGA connector with the longer connector side to the left.
Ê Fasten the front VGA connector in the front panel module with two hexagon
bolts.
13.2.1.5 Re-installing the front panel module
Ê "Installing the front panel module" on page 313
