Fujitsu PRIMERGY RX2520 M1 - SAS Cabling

374 Upgrade and Maintenance Manual RX2520 M1
Conversion configurations
15.1.2 SAS cabling
9
12x 3.5-inch
HDD
n.a.
Config Cable from to
1 C24 X1 rear pass-through
board
MLC1 -SAS controller
C24 X1 front pass-through
board
MLC2 -SAS controller
2 C10 X1 - 4x 2.5-inch HDD Bpl SAS1-4 system board
2 (with
controller)
C10 X1 - 4x 2.5-inch HDD Bpl MLC1 -SAS controller
3 C10 X1 - 4x 2.5-inch HDD Bpl MLC1 -SAS controller
4 C9 X1 - 4x 2.5-inch HDD Bpl MLC1 -SAS controller
C10 X1 - 4x 2.5-inch HDD Bpl MLC2 -SAS controller
5 C8 X1 - 4x 2.5-inch HDD Bpl MLC1 -SAS controller
C10 X1 - 4x 2.5-inch HDD Bpl MLC2 -SAS controller
6 C10 X1 - 4x 2.5-inch HDD Bpl MLC1 -SAS controller
C11 X1 - 4x 2.5-inch HDD Bpl MLC2 -SAS controller
7 C9 X1 - 12x 2.5-inch HDD Bpl MLC1 -SAS controller
C9 X2 - 12x 2.5-inch HDD Bpl MLC2-SAS controller
8 C7 X1 - 4x 2.5-inch HDD Bpl X3 - 12x 2.5-inch HDD Bpl
C9 X1 - 12x 2.5-inch HDD Bpl MLC1 -SAS controller
C9 X2 - 12x 2.5-inch HDD Bpl MLC2 -SAS controller
9 C24 X1 rear expander board MLC1 -SAS controller
C24 X1 front expander board MLC2 -SAS controller
