RX2520 M1
Upgrade and Maintenance Manual 293
Accessible drives
Ê Fasten the tape drive dummy module with 2 screws.
Ê Insert the drive cage into bay 2, for further information see sectjon "Installing
the RDX drive" on page 286.
Ê Insert the HDD cage into bay 1, for further information see sectjon "Installing
a HDD cage" on page 159.
Ê If applicable, remove the USB 3.0 interface card as describe in section
"Removing an expansion card" on page 189
12.8.4 Concluding steps
Ê "Installing the fan box" on page 171
Ê "Reassembling" on page 59
Ê "Connecting the server to the power source" on page 64
Ê "Switching on the server" on page 66
Ê "Verifying and configuring the backup software solution" on page 81
Ê "Enabling BitLocker functionality" on page 93
12.9 Replacing the RDX drive in 2.5-inch version
12.9.1 Preliminary steps
Ê "Disabling or suspending BitLocker functionality" on page 67
Ê "Locating the defective server" on page 49
Ê "Removing backup and optical disk media" on page 71
Ê "Verifying and configuring the backup software solution" on page 71
Ê "Shutting down the server" on page 51
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
