338 Upgrade and Maintenance Manual
RX2520 M1
System board and components
14.3.1.2 Installing the UFM
Figure 229: UFM kit
Figure 230: UFM mounting location
1 USB Flash Module (UFM) 2 UFM spacer
3 UFM nylon screw
1 Cut-out for UFM spacer 2 UFM connector
