158 Upgrade and Maintenance Manual RX2520 M1
Hard disk drives / solid state drives
7.5 HDD cage
7.5.1 Removing a HDD cage
Figure 66: Disconnecting cables from the 4x 2.5-inch HDD SAS backplane
Ê Disconnect all cables from the 4x 2.5-inch HDD SAS backplane:
– SAS / SATA cable
– Power cables
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
