Ê Connect the power cable to the ODD (1).
Ê Connect the SATA cable to the ODD (2).
Figure 167: Installing the ODD
Ê Insert the ODD into the bay and push in until it locks in place (3).
12.6.1.5 Concluding steps
Ê "Installing the fan box" on page 171
Ê "Reassembling" on page 59
Ê "Connecting the server to the power source" on page 64
Ê "Enabling BitLocker functionality" on page 93
12.6.2 Removing the optical disc drive (ODD)
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: Phillips PH0 / (+) No. 0 screw driver
