Figure 180: Installing the RDX drive cage
Ê Fasten the drive cage with the screw.
Figure 181: Connecting the USB cable to the USB 3.0 interface card
Ê Connecting the power cable C5 to the RDX drive (1).
Ê Connecting the USB cable C22 to the RDX drive (2).
Ê Route the cables as shown.
Ê Connect the USB cable C22 to the USB 3.0 interface card (3).
