Ê "Shutting down the server" on page 51
Ê "Disconnecting power cords" on page 52
Ê Take the system down to its minimum startup configuration.
Ê "Connecting the server to the power source" on page 64
Ê Connect a keyboard, mouse and display to the server.
Ê "Switching on the server" on page 66
V CAUTION!
Since the fan module is not included in the minimum startup
configuration, the server must be shut down immediately after the
diagnostic process is complete (POST phase has been passed).
The minimum startup configuration must be used exclusively for
diagnostic purposes by maintenance personnel, never in daily
operation!
Component Notes
System board no TPM, UFM or expansion cards installed
CPU with CPU heat sink
1 memory module installed in DIMM slot 1A
Front panel module
Power supply unit
Table 12: Minimum startup configuration - components
Cable Notes
Front panel cable
Power cable
Table 13: Minimum startup configuration - cables
