APPENDIX I: FACTORY DEFAULT CONFIGURATION I.2 FACTORY DEFAULT CONFIGURATION
GEK-106310-AF F650 DIGITAL BAY CONTROLLER i-29
SETPOINT > RELAY CONFIGURATION > PROTECTION ELEMENTS
PROTECTION ELeMENT SOURCE SIGNAL LOGIC SOURCE LOGIC
LED RESET INPUT OPERATION BIT 3
CHANGE LOCAL-REMOTE Not Configured
CHANGE OP BLOCKED Not Configured
HMI BACKLIGHT ON Not Configured
HMI BACKLIGHT OFF Not Configured
PH IOC1 HIGH A BLK
GROUP 1 BLOCKED
CONT IP_F_CC2 (50P BLOCK)(CC2)
PHASE DIR1 A OP NOT
LATCHED VIRT IP 1
PH IOC1 HIGH B BLK
GROUP 1 BLOCKED
CONT IP_F_CC2 (50P BLOCK)(CC2)
PHASE DIR1 B OP NOT
LATCHED VIRT IP 1
PH IOC1 HIGH C BLK
GROUP 1 BLOCKED
CONT IP_F_CC2 (50P BLOCK)(CC2)
PHASE DIR1 C OP NOT
LATCHED VIRT IP 1
PH IOC2 HIGH A BLK
GROUP 2 BLOCKED
CONT IP_F_CC2 (50P BLOCK)(CC2)
PHASE DIR2 A OP NOT
LATCHED VIRT IP 1
PH IOC2 HIGH B BLK
GROUP 2 BLOCKED
CONT IP_F_CC2 (50P BLOCK)(CC2)
PHASE DIR2 B OP NOT
LATCHED VIRT IP 1
PH IOC2 HIGH C BLK
GROUP 2 BLOCKED
CONT IP_F_CC2 (50P BLOCK)(CC2)
PHASE DIR2 C OP NOT
LATCHED VIRT IP 1
PH IOC3 HIGH A BLK
GROUP 3 BLOCKED
CONT IP_F_CC2 (50P BLOCK)(CC2)
PHASE DIR3 A OP NOT
LATCHED VIRT IP 1
PH IOC3 HIGH B BLK
GROUP 3 BLOCKED
CONT IP_F_CC2 (50P BLOCK)(CC2)
PHASE DIR3 B OP NOT
LATCHED VIRT IP 1
PH IOC3 HIGH C BLK
GROUP 3 BLOCKED
CONT IP_F_CC2 (50P BLOCK)(CC2)
PHASE DIR3 C OP NOT
LATCHED VIRT IP 1
PH IOC1 LOW A BLK
GROUP 1 BLOCKED
CONT IP_F_CC2 (50P BLOCK)(CC2)
PHASE DIR1 A OP NOT
LATCHED VIRT IP 2
