CHAPTER 9: BOOTCODE AND FIRMWARE UPGRADE 9.1 FIRMWARE UPGRADE VERSIONS BELOW 7.00.
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 9-3
9.1.1 Communication parameters
1. Ethernet Connection/Type - Both boot code and firmware upgrade processes require Ethernet communications. It is
strongly recommended to use a direct connection between the PC and the relay using a Cross-Over RJ45 Ethernet
cable, instead a direct connection through a hub or switch.
Upgrading through Local Area Network (LAN) must be
avoided.
Serial RS232 Communication - Serial communication is necessary only to perform the bootware upgrade for versions
previous to 7.00.
2. Relay IP Address - An IP address must be assigned to the relay in the Ethernet parameters via HMI at Product Setup >
Communication > Ethernet > Ethernet1 menu, or via Enervista 650 Setup software at Setpoint > Product Setup >
Communication Settings > Network (Ethernet) 1 a
s shown in the table below:
Table 9-1: Ethernet parameters
3.
PC IP Address - In case the boot code has been previously updated to the relay (section 9.2), the IP address and other
parameters already assigned in the process are:
IP Address:192.168.37.177
Netmask:255.255.255.0
Gateway:192.168.37.10
Then the PC settings should be the same pattern as follows:
IP Address:192.168.37.xxx
Netmask:255.255.255.0
Gateway:192.168.37.10 (if desired)
Where XXX is a number between 0 and 255 that is not assigned to any other device to avoid collisions.
4. Other Network, Communications and Data Flow checks
• According to the model number of the relay, to enable the 10
/100 BASE TX-CABLE option in the relay communication
board, a specific jumper in this board must be changed. See detailed instructions in paragraph 3.4.3 of Instruction
Manual GEK-106310AE.
• IP address, netmask, gateway are correct and match the paramet
ers used in the computer to perform the procedure.
See table 9.1 (on this chapter) of Manual GEK-106310AE COMMUNICATION PARAMETERS.
Product Setup > Communication Settings > Network (Ethernet) 1
Name Value Units Range
IP Address Oct1 192 [0 : 255]
IP Address Oct2 168 [0 : 255]
IP Address Oct3 37 [0 : 255]
IP Address Oct4 177 [0 : 255]
Netmask Oct1 255 [0 : 255]
Netmask Oct2 255 [0 : 255]
Netmask Oct3 255 [0 : 255]
Netmask Oct4 0 [0 : 255]
Gat eway I P Oct1 192 [0 : 255]
Gat eway I P Oct2 168 [0 : 255]
Gat eway I P Oct3 37 [0 : 255]
Gat eway I P Oct4 10 [0 : 255]
