4-32 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
4.1 ENERVISTA 650 SETUP SOFTWARE CHAPTER 4: INTERFACES, SETTINGS & ACTUAL VALUES
4.1.9 Operations menu
Option only available in online mode, showing all the operations previously configured in the relay with their
corresponding texts, which must be different from the default text (Op_X not configured).
(*) indicates online only, (**) indicates offline only
4.1.10 Communications menu
The communication menu includes the computer screen to start communicating with the relay, the different update
procedures available in device: firmware, operating system, web server and other file storing capabilities (upload and
download info files to/from relay).
For more detail information go to section 4.1.3 Connect to the relay for communication menus description and to section 5
for flash memory update procedures.
(*) indicates online only, (**) indicates offline only
operations
Operation 1 (*) Entry to first operation (with its corresponding text)
... ...
Operation 24 (*)
Entry to 24
th
operation (with its corresponding text)
Communication
Computer Menu to start communication with the relay.
Modem (**) Configure the unit for remote communications via modem, using a telephone line. This is
only available if the relay is not communicating and if modem has been selected under
Communication > Computer control type.
Troubleshooting (*) Read/write to ModBus addresses, for verifying communications and access to different
positions in the ModBus memory map. Only available if the communication has already
been established.
Calibration (*) Retrieve the unit calibration settings and storing them in a file (with extension *.cal). For
reading or storing the calibration settings in the relay go to Communications >
Calibration > Get or Set calibration settings and select the intended calibration file. The
calibration retrieval process must be performed before updating the operating system.
When the firmware and bootcode are updated, all the data in the relay is deleted,
including the factory calibration settings. When only the firmware is updated (for versions
higher than 1.50), the calibration settings are automatically saved in the relay.
Upgrade relay (**) Upgrade firmware version (Ethernet connection): Update the relay firmware through
Ethernet communication . Firmware is related to the relay internal program, designed by
GE Multilin, which performs the protection and control functions, and which is run by the
relay main microprocessor.
Upgrade 650 web
server
Upgrade 650 web server (Ethernet connection):Go to Communications > Upgrade 650 web
server. The relay web server application can be updated to further versions (if available)
using this menu without modifying the relay operating system.
Upload info files to
relay
Upload info files to relay (Ethernet connection): This functionality is used to store setting
files (*.650) inside the relay, as well as auxiliary files used by the programmable logic
graphical editor (*.pep, *.aut, *.lib).
Download info files
from relay
Download info files from relay (Ethernet connection): This functionality is used for
retrieving the files (*.650 and *.pep, *.aut, *.lib) that have been previously stored in the
relay flash memory.
