7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
7.2.7.3.3 PICS for 650 family of relays whose order code has Rear Ethernet Communication Board 2
option "H", "G", "K", "J", "L", "M" and IEC 61850 Edition 1
Reference documentation: PICS For F650 relay V1_6 firm7_52.
This document describes the:
• ACSI Conformance Statement
• PICS ("Protocol Implementation Conformance Statement") for 650 family of relays.
1 General
The following ACSI conformance statements are used to provide an overview and details about F650 bay controller, with
firmware 7.52:
• ACSI BASIC conformance statement.
• ACSI MODELS conformance statement.
• ACSI SERVICE conformance statement.
The statements specify the communication features mapped to IEC 61850-8-1 First Edition and/or Edition 2.
2 ASCI basic conformance statement
The basic conformance statement is defined in Table 7-5: Basic conformance statement
Table 7-5: Basic conformance statement
Client/
Subscriber
Server/
Publisher
Value/ Comments
Client-Server roles
B11
Server side (of TWO-PARTY-APPLICATION-
ASSOCIATION)
Y
B12
Client side of (TWO-PARTY-APPLICATION-
ASSOCIATION)
SCSMs supported
B21 SCSM: IEC 6185-8-1 used Y
B22 SCSM: IEC 6185-9-1 used Ed2:Deprecated
B23 SCSM: IEC 6185-9-2 used
B24 SCSM: other
Generic substation event model (GSE)
B31 Publisher side Y
B32 Subscriber side Y
Transmission of sampled value model (SVC)
B41 Publisher side
B42 Subscriber side
–
Y = supported
N or empty = not supported
