5-38 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
5.3 SYSTEM SETUP CHAPTER 5: SETPOINTS
5.3.5 Switchgear settings
There is the possibility to enable or disable the generation of internal signals for the different elements (protection, control,
inputs and outputs, switchgear) available in the device.
(KI)
2
t PHASE B Accumulated (KI)
2
t value for phase B ((KI)
2
t Counter for Phase B)
(KI)
2
t PHASE C Accumulated (KI)
2
t value for phase C ((KI)
2
t Counter for Phase C)
BKR OPENING TIME Maximum breaker Opening time. This signal is configured at Setpoint > Re
lay Configuration
>Switchgear in the number of switchgear corresponding to the breaker selection
BKR CLOSING TIME Maximum breaker Closing time. This signal is configured at S
etpoint > Relay Configuration
>Switchgear in the number of switchgear corresponding to the breaker selection
BKR OPEN TIMING Exact time in opening the breaker
BKR CLOSE TIMING Exact time in closing the breaker
Setpoint > System Setup > Switchgear
Setting Description Name Default
Value
Step Range
Snapshot Event generation for switchgear #1 Snapshot Events SWGR 1 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #2 Snapshot Events SWGR 2 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #3 Snapshot Events SWGR 3 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #4 Snapshot Events SWGR 4 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #5 Snapshot Events SWGR 5 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #6 Snapshot Events SWGR 6 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #7 Snapshot Events SWGR 7 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #8 Snapshot Events SWGR 8 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #9 Snapshot Events SWGR 9 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #10 Snapshot Events SWGR 10 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #11 Snapshot Events SWGR 11 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #12 Snapshot Events SWGR 12 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #13 Snapshot Events SWGR 13 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #14 Snapshot Events SWGR 14 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #15 Snapshot Events SWGR 15 DISABLED N/A [DISABLED – ENABLED]
Snapshot Event generation for switchgear #16 Snapshot Events SWGR 16 DISABLED N/A [DISABLED – ENABLED]
