LOGIC OPERANDS
A.1 Operands - F650 - model FX - GX
OPERANDS - F650 - MODEL FX - GX
Internal System Status
autocheck internal states (critical)
DSP Internal States (Critical to metering and
pr
otection)
DSP COMM ERROR
DSP Communication Error: (0) Rignt communications
between DSP and ma
in processor; (1) Communication
Error between DSP and main processor
MAGNETIC MODULE
ERR
OR
Magnetic Module Error: (0) Right Communication
between DSP and ma
gnetic module processor; (1)
Communication Error between DSP and magnetic
module processor
CALIBRATION ERROR
Calibration Error: (0) Right calibration values stored; (1)
The
calibration values stored are out of the calibration
limits.
Flash Internal States (Critical to Relay configuration
and st
ored data)
E2PROM STATUS
E2prom status :(0) Not configured or problems during
wr
iting process ; (1) Configured and OK
IO Board States (Critical to operation and
pr
otection)
BOARD F STATUS
Board F status: (0) Inactive - There is no communication
with the boar
d (1) Active - There is communication with
the board.
BOARD G STATUS
Board G status: (0) Inactive - There is no communication
with the boar
d (1) Active - There is communication with
the board.
BOARD H STATUS
Board H status: (0) Inactive - There is no communication
with the boar
d (1) Active - There is communication with
the board.
BOARD J STATUS
Board J status: (0) Inactive - There is no communication
with the boar
d (1) Active - There is communication with
the board.
IEC61850 INTERNAL STATES (NON CRITICAL)
