2-28 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
2.5 TECHNICAL SPECIFICATIONS CHAPTER 2: PRODUCT DESCRIPTION
2.5.12 Environmental
Operating Temperature:........................................................- 10°C to + 60°C
Storage Temperature:............................................................- 40°C t
o + 85°C
Humidity (non-condensing):................................................95%
Altitude:.........................................................................................up to 2000 m
Class of Equipment:.................................................................I
Equipment Mobility: ................................................................fixed
Overvoltage Category:...........................................................III
Pollution Degree:.......................................................................2
2.5.13 Packaging and weight
Net Weight:..................................................................................5 kg
Packaged Weight:....................................................................6 kg
Package Dimensions: .............................................................30 x 40 x 40 cm (D x W x H)
2.5.14 Type tests
Type test report available upon request.
F650 has been designed to comply with the highest existing requirements. More specifically, UNIPEDE recommendations
for high voltage substations are followed, even if for most applications such high classes are not required.
The relay complies with ANSI C37.90 standards, and has been designed to comply with international standards.
CATEGORY STANDARD CLASS TEST
SAFETY
Dielectric voltage withstand IEC60255-27 2 KV / 2.3 KV
Impulse voltage withstand IEC60255-27 5 KV
Insulation resistance IEC60255-27 500 V (test level)
EMC
Electrostatic Discharge Immunity IEC60255-26/IEC61000-4-2 Level 4
Radiated RF Electromagnetic Field Immunity IEC60255-26/IEC61000-4-3 Level 3
Electrical Fast Transient Immunity IEC60255-26/IEC61000-4-4 Zone A
Surge Immunity IEC60255-26/IEC61000-4-5 Zone A
Conducted RF Immunity IEC60255-26/IEC61000-4-6 Level 3
Power magnetic Immunity IEC60255-26/IEC61000-4-8 Level 5
Power Frequency Immunity IEC60255-26/IEC61000-4-16 Zone A
Damped Oscillatory Wave Immunity IEC60255-26/IEC61000-4-18
2.5 KV Common Mode 1 KV Diff. Mode
Voltage Dips & Interruptions IEC60255-26/IEC61000-4-11/
IEC61000-4-29
Levels based on IEC61000-4-11 &
IEC61000-4-29
Ripple on DC IEC60255-26/IEC61000-4-17 15% Rated DC value
Radiated & Conducted Emissions IEC60255-26/CISPR11/
CI
SPR22
Class A
MECHANICAL
Sinusoidal Vibration IEC60255-21-1 Class 1
Shock & Bump IEC60255-21-2 Class 1
Seismic IEC60255-21-3 Class 2
Enclosure Protection IEC60255-27/IEC60529 IP52
CLIMATIC
Cold test (storage) IEC60068-2-1 -40˚C 16 hrs
Cold test (operational) IEC60068-2-1 -20˚C 16 hrs
Dry heat test (storage) IEC60068-2-2 85˚C 16 hrs
Dry heat test (operational) IEC60068-2-2 60˚C 16 hrs
Change of Temperature IEC60068-2-14 5 cycles (3+3) -20˚C/6
0˚C
Damp Heat Humidity Cyclic IEC60068-2-30 6 cycles (12+12) 55˚C @ 93% R.H.
Damp Heat steady state IEC60068-2-78 40˚C
@ 93% R.H.
