7-184 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
7.2.7.3.10 PIXIT for 650 family of relays whose order code has Rear Ethernet Communication Board 2
option "B", "C", "D", "E" and IEC 61850 Edition 1
Reference documentation: PIXIT for 650 family of relays v1_5 firm3_60.
This document describes the:
• PIXIT for Association Model
• PIXIT for Server model
• PIXIT for Dataset model
• PIXIT for Reporting model
• PIXIT for Generic substation events model
• PIXIT for Control model
• PIXIT for Time and time synchronisation model
• PIXIT for File transfer model
This document specifies the protocol implementation extra information for testing (PIXIT) of the IEC 61850 interface in 650
family of relays
Together with the PICS and the MICS the PIXIT forms the basis for a conformance test according to IEC 61850-10.
Contents of this document: Each chapter specifies the PIXIT for each applicable ACSI service model as structured in IEC
61850-10.
1 Pixit For Association Model
Description Value / Clarification
Maximum number of clients that can set-up an
a
ssociation simultaneously
5
Lost connection detection time range (default range of
T
CP_KEEPALIVE is 1 – 20 seconds)
20 seconds
Is authentication supported N
What association parameters are necessary for
successf
ul association
Only local selectors are checked:
Transport selector Y (00 01)
Session selector Y (00 01)
Presentation selector Y (00 00 00 01)
AP Title N
AE Qualifier N
What is the maximum and minimum MMS PDU size Max MMS PDU size : 256000
There is no established minimum MMS PDU size, however
r
ecommended MMS PDU size is at least 32000.
What is the typical startup time after a power supply
int
errupt
210 SECONDS
