GE Multilin F650 - Page 589

CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-183
NOTE: Tissue 49, 190, 191, 275 and 278 are part of tissue #453, all other technical tissues in the table are mandatory if
applicable.
NOTE: Editorial tissues are marked as "na".
7-2 30
31
32
35
36
37
39
40
41
42
43
44
45
46
47
49
50
51
52
53
151
166
185
189
190
191
278
297
298
305
322
329
333
335
348
349
453
1281
control parameter T
Typo
Typo in syntax
Typo Syntax Control time
Syntax parameter DSet-Ref missing
Syntax GOOSE "T" type
Add DstAddr to GoCB
GOOSE Message "AppID" to "GoID"
GsCB "AppID" to "GsID"
SV timestamp: "EntryTime" to "TimeStamp"
Control "T" semantic
AddCause - Object not sel
Missing AddCauses
Synchro check cancel
"." in LD Name?
BRCB TimeOfEntry (part of #453)
LNName start with number?
ARRAY [0..num] missing
Ambiguity GOOSE SqNum
Add DstAddr to GsCB, SV
Name constraint for control blocks etc.
DataRef attribute in Log
Logging - Integrity periode
SV Format
BRCB: EntryId and TimeOfEntry (part of #453)
BRCB: Integrity and buffering reports (part of #453)
EntryId not valid for a server (part of #453)
Sequence number
Type of SqNum
Reporting with BufTm = 0
Write Configuration attribute of BRCBs
Reporting and BufOvl
Enabling of an incomplete GoCB
Clearing of BufOvfl
URCB class and report
BRCB TimeOfEntry has two definitions
Combination of all reporting and logging tissues
Trigger option GI is by default
na
na
na
Y
na
na
na
na
Y
na
na
na
na
na
na
-
na
na
na
na
na
na
na
na
-
-
-
na
na
na
na
na
na
na
na
na
na
na
Part 6 1
5
8
10
17
169
245
529
Syntax
tExtensionAttributeNameEnum is restricted
SIUnit enumeration for W
Base type for bitstring usage
DAI/SDI elements syntax
Ordering of enum differs from 7-3
Attribute RptId in SCL
Replace sev - Unknown by unknown
na
Y
Y
Y
Y
na
na
na
