5.2 Product setup
5.2.1 Communication settings
5.2.1.1 Serial ports
Baud rate and parity for COM1 and COM2 serial communication ports.
5.2.1.2 Network (Ethernet)
Depending on the firmware version the Network (Ethernet) setting window vary.
For versions previous to 7.00 of firmware; the network Ethernet window settings are for configure Ethernet communication
parameters for ETH_1/ETH2 (Depending on model). Two different Ethernet addresses can be used, but the first IP always
has to be set as the second IP Address is an Alias. The ModBus Slave address used by Ethernet ports is the one set for
COM2.
Table 5-2: NETWORK settings for firmware versions previous to 7.00
For firmware versions 7.00 or higher; the Network settings are the Ethernet communication parameters for Port A, Port B
and Port E. Depending on the order code, up to three different Ethernet addresses can be used, The ModBus Slave address
used by Ethernet ports is the one set for COM2.
Table 5-3: Network settings for firmware version 7.00 and above
Product Setup > Communication settings >Serial Ports
Name Default Value Step Range
COM1 Baud Rate 19200 N/A [300 : 115200]
COM2 Baud Rate 19200 N/A [300: 115200]
COM1Parity NONE N/A [NONE:ODD:EVEN]
COM2Parity NONE N/A [NONE:ODD:EVEN]
Product Setup > Communication settings >Network (Ethernet) Network (Ethernet)1> NETWORK
(ETHERNET)2
Name Default Value Step Range
IP Address Oct1 0 N/A [0: 255]
IP Address Oct2 0 N/A [0: 255]
IP Address Oct3 0 N/A [0: 255]
IP Address Oct4 0 N/A [0: 255]
Netmask Oct1 0 N/A [0: 255]
Netmask Oct2 0 N/A [0: 255]
Netmask Oct3 0 N/A [0: 255]
Netmask Oct4 0 N/A [0: 255]
Gateway IP Oct1 0 N/A [0: 255]
Gateway IP Oct2 0 N/A [0: 255]
Gateway IP Oct3 0 N/A [0: 255]
Gateway IP Oct4 0 N/A [0: 255]
PRODUCT SETUP > COMMUNICATION SETTINGS >NETWORK (ETHERNET) NETWORK (ETHERNET)A>
NETWORK (ETHERNET)B> NETWORK (ETHERNET) E > REDUNDANCY
