CHAPTER 5: SETPOINTS 5.2 PRODUCT SETUP
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 5-5
IP ADDRESS: This setting sets the ports IPv4 address in standard IPV4 format. Note that this setting is only valid on port B if
port A’s REDUNDANCY is set to INDEPENDENT.
NETMASK: This setting sets the ports IPv4 subnet mask in standard IPV4 format. Note that this setting is only valid on port
B if port A’s REDUNDANCY is set to INDEPENDENT.
Table 5-4: Redundancy settings
REDUNDANCY MODE: This setting is available only if the hardware has multiple ports. The setting determines if ports A and B
operate in redundant or independent mode. Different options are liste below:
·-Independent: In non-redundant mode, port A and B operate independently with their own MAC, IP address,
mask and gateway.
NOTE: When using more than one Ethernet port, each port must be configured to belong to a different network,
otherwise communications becomes unpredictable.
NOTE 2: When non-redundant mode is selected, MAC address assigned to port A is the same as MAC address
assigned to port E but increased in one unit and MAC address assigned to port B is the same as MAC address
assigned to port A but increased in one unit.
E.g (MAC_portE: 00AFF40A24DA, MAC_portA:00AFF40A24DB, MAC_portB: 00AFF40A24DC)
· LLA (Link Loss) operation: The operation of ports A and B are as follows:
Ports A and B use port A’s MAC and IP address settings while port B is in standby mode in that it does not actively
communicate on the Ethernet network but monitors its link.
· PRP (Parallel Redundancy Protocol): ports A and B use the same MAC (physical device) address and combine
information at the link layer. It is intended to only be used if the two ports are connected to separate parallel LAN’s.
In this mode of operation both ports cannot be connected to the same LAN. The receiving devices process the first
NAME
DEFAULT
VALUE STEP RANGE USER VALUE
IP Address Oct1 0 N/A [0 : 255]
IP Address Oct2 0 N/A [0 : 255]
IP Address Oct3 0 N/A [0 : 255]
IP Address Oct4 0 N/A [0 : 255]
Netmask Oct1 0 N/A [0 : 255]
Netmask Oct2 0 N/A [0 : 255]
Netmask Oct3 0 N/A [0 : 255]
Netmask Oct4 0 N/A [0 : 255]
PRODUCT SETUP > COMMUNICATION SETTINGS > NETWORK (ETHERNET) > REDUNDANCY
NAME DEFAULT VALUE STEP RANGE
REDUNDANCY MODE INDEPENDENT N/A
[INDEPENDENT; LLA; PRP; HSR; RSTP;
DAISY_CHAIN]
LLA Priority DISABLED N/A [ENABLED; DISABLED]
LLA Timeout 5000 N/A [0 : 600000]
RSTP BRIDGE PRIORITY 32768 N/A [0 : 61440]
RSTP PORT A PRIORITY 128 N/A [0 : 240]
RSTP PORT A PATHCOST 200000 N/A [0 : 2000000]
RSTP PORT B PRIORITY 128 N/A [0 : 240]
RSTP PORT B PATHCOST 200000 N/A [0 : 2000000]
