GE Multilin F650 - Real Time Clock; Outputs; Control Power Supply

2-24 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
2.5 TECHNICAL SPECIFICATIONS CHAPTER 2: PRODUCT DESCRIPTION
2.5.7 Real time clock
Accuracy: .....................................................................................typical ±20 ppm
Backup Energy: .........................................................................more than 1 week
Note: For r
elay versions before 7.00, when the relay date and time is changed using any documented methods (Modbus, IRIG-B, SNTP,
Front Panel...) the relay acknowledges and updates the time instantly but it takes nearly 3 minutes for the new time to be permanently
stored in the Real Time Clock’s NVRAM.
2.5.8 Outputs
OUTPUTS
Single Contact Carry continuous:.....................................16 A
Make and Carry for 1 s:.........................................................60 A
Break at L/R of 40 ms:............................................................0.3 A DC max. at 125 Vdc
0.25 A DC max. at 250 Vdc
Operate Time: ............................................................................< 8 ms
Contact Material: ......................................................................silver alloy
Output Logic Type, Output Type and Pulse Output Time are selectable by setting for each output
Output Logic Type:...................................................................positive/negative
Output Type:...............................................................................normal/pulse/latch (selectable by setting for each output)
Pulse Output Time: ..................................................................0 to 60000 ms in steps of 1 ms (applicable only to signals sent as pulse type)
Separate operate and reset signals can be configured by any digital signal programmable through the PLC
Contact Outputs (F31-F33, F34-F36) for board type
2 (supervision) in slot F: ....................................................The current seal-in circuit is used for verifying the current condition in a circuit during
the tim
e that the tripping contact remains closed. If the current in the tripping circuit is
maintained over 500 mA, the function is sealed independently of the status of the
function that caused the trip.
REMOTE OUTPUTS (IEC61850 GSSE/GOOSE)
Standard Output Points:........................................................32
User Output Points:..................................................................32
2.5.9 Control power supply
LOW RANGE (LO) ALL RANGES
Nominal DC Voltage: 24 to 48 V Power Consumption: Typical =25 VA, Maximum =45 VA
Min/Max DC Voltage 19.2 / 57.6 V Display backlight auto power-off mode after 15 minutes without touching
any key
, in order to ensure long life and
minimum consumption
Note: Low range is DC only
Voltage Loss hold-up time:(*) 24 Vdc 30 ms
48 Vdc 100 ms
(*) These figures have been calculated for models wit
h the following characteristic:
- IEC Symbols Graphic display
- Rear Ethernet Communication Board 2: PRP, 1588, 10/100 Base TX+ Redundant 100 Base FX
- F and G I/O Board:
Slot F: 8 Digital Inputs + 8 Output
s + 2 Trip / Close circuit supervision circuits
Slot G: 16 Digital Inputs + 8 Outputs
HIGH RANGE (HI) INTERNAL FUSE
Nominal DC Voltage: 110 to 250 V V: 250 VAC
Min/Max DC Voltage 88 / 300 V I: 2.5A
Nominal AC Voltage: 120 to 230 V Size: 5 x 20 mm
Min/Max AC Voltage: 102 / 250 V Type: Quick acting (F)
Voltage Loss Hold-up Time: 200 ms typical
100 ms worst case
UL listed miniature Fuse
