GE Multilin F650 - Multiple Setting Groups

CHAPTER 5: SETPOINTS 5.4 PROTECTION ELEMENTS
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 5-45
5.4.1.2.2 Multiple setting groups
In this mode, all protection elements are available in each individual setting group (up to maximum of 6). Only one
configured setting groups is active at a given time. A logic signal, e.g. a digital input, selects which table is active at each
time, providing adaptive protection to each network condition.
The distribution of protection elements in groups is described in Table 5–33:
Table 5-19: DISTRIBUTION OF PROTECTION ELEMENTS
The settings used for setting group management are located in Setpoint >Control Elements > Setting Group
SETTING GROUP 1 SETTING GROUP 2 SETTING GROUP 3 SETTING GROUP 4 SETTING GROUP 5 SETTING GROUP 6
3x50PH 3x50PH 3x50PH 3x50PH 3x50PH 3x50PH
3x50PL 3x50PL 3x50PL 3x50PL 3x50PL 3x50PL
3x50N 3x50N 3x50N 3x50N 3x50N 3x50N
3x50G 3x50G 3x50G 3x50G 3x50G 3x50G
3x50SG 3x50SG 3x50SG 3x50SG 3x50SG 3x50SG
3x50IG 3x50IG 3x50IG 3x50IG 3x50IG 3x50IG
3x51PH 3x51PH 3x51PH 3x51PH 3x51PH 3x51PH
3x51PL 3x51PL 3x51PL 3x51PL 3x51PL 3x51PL
3x51N 3x51N 3x51N 3x51N 3x51N 3x51N
3x51G 3x51G 3x51G 3x51G 3x51G 3x51G
3x51SG 3x51SG 3x51SG 3x51SG 3x51SG 3x51SG
3x46P 3x46P 3x46P 3x46P 3x46P 3x46P
3x49P 3x49P 3x49P 3x49P 3x49P 3x49P
3x67P 3x67P 3x67P 3x67P 3x67P 3x67P
3x67N 3x67N 3x67N 3x67N 3x67N 3x67N
3x67G 3x67G 3x67G 3x67G 3x67G 3x67G
3x67SG 3x67SG 3x67SG 3x67SG 3x67SG 3x67SG
3x27P 3x27P 3x27P 3x27P 3x27P 3x27P
3x59P 3x59P 3x59P 3x59P 3x59P 3x59P
3x47P 3x47P 3x47P 3x47P 3x47P 3x47P
3x59NH 3x59NH 3x59NH 3x59NH 3x59NH 3x59NH
3x59NL 3x59NL 3x59NL 3x59NL 3x59NL 3x59NL
3x59X 3x59X 3x59X 3x59X 3x59X 3x59X
3x27X 3x27X 3x27X 3x27X 3x27X 3x27X
3x32FP 3x32FP 3x32FP 3x32FP 3x32FP 3x32FP
3x32 3x32 3x32 3x32 3x32 3x32
3x32N High 3x32N High 3x32N High 3x32N High 3x32N High 3x32N High
3x32N Low 3x32N Low 3x32N Low 3x32N Low 3x32N Low 3x32N Low
6x81U 6x81U 6x81U 6x81U 6x81U 6x81U
6x81O 6x81O 6x81O 6x81O 6x81O 6x81O
3 x Broken conductor 3 x Broken conductor 3 x Broken conductor 3 x Broken conductor 3 x Broken conductor 3 x Broken conductor
3 x Locked Rotor 3 x Locked Rotor 3 x Locked Rotor 3 x Locked Rotor 3 x Locked Rotor 3 x Locked Rotor
3 x Freq. Rate of
Change
3 x Freq. Rate of
Change
3 x Freq. Rate of
Change
3 x Freq. Rate of
Change
3 x Freq. Rate of
Change
3 x Freq. Rate of
Change
3 x Load
Encroachment
3 x Load
Encroachment
3 x Load
Encroachment
3 x Load
Encroachment
3 x Load
Encroachment
3 x Load
Encroachment
