6-16 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
6.2 STATUS CHAPTER 6: ACTUAL VALUES
6.2.4.12 Maximum number of starts
This screen can be accessed at Actual > Status > Control Elements > Max. Number of Starts, and it includes one LEDs
for the Maximum Number of Starts function, indicating the activation of the unit. There are also two magnitudes global starts
and block lockout time.
Table 6-21: Table 6-24: Maximum number of starts actual values
6.2.4.13 Digital counters
This screen can be accessed at Actual > Status > Control Elements > Digital Counters, and it includes 24 LEDs for the
8 Digital Counters status, indicating which status is activate (HI, LO or EQ).
Table 6-22: Digital counter actual values
MAX. NUMBER OF STARTS
ACTUAL VALUES
NUMBER OF STARTS OP
GLOBAL STARTS CNT
BLOCK LOCKOUT TIME
DIGITAL COUNTERS ACTUAL
VALUES
DIGCNT 1 HI
DIGCNT 2 HI
DIGCNT 3 HI
DIGCNT 4 HI
DIGCNT 5 HI
DIGCNT 6 HI
DIGCNT 7 HI
DIGCNT 8 HI
DIGCNT 1 EQ
DIGCNT 2 EQ
DIGCNT 3 EQ
DIGCNT 4 EQ
DIGCNT 5 EQ
DIGCNT 6 EQ
DIGCNT 7 EQ
DIGCNT 8 EQ
DIGCNT 1 LO
DIGCNT 2 LO
DIGCNT 3 LO
DIGCNT 4 LO
DIGCNT 5 LO
DIGCNT 6 LO
DIGCNT 7 LO
DIGCNT 8 LO
DIGCNT 1 VALUE
DIGCNT 2 VALUE
DIGCNT 3 VALUE
DIGCNT 4 VALUE
DIGCNT 5 VALUE
DIGCNT 6 VALUE
DIGCNT 7 VALUE
