C.6 Binary output and control relay output
Supported Control Relay Output Block fields: Pulse On.
The F650 relay provides 24 DNP Binary/Control Output points. These outputs are mapped to the first 24 commands
configured in the F650. Executing a command is equal to activate the PLC equation that was attached to this command.
Thus all of the 24 DNP Binary/Control Output points are pulsed points. It means that only Pulse On flag is accepted in DNP
control operations on those points. All commands have configurable names. Changing the command’s name can be done
using the EnerVista 650 Setup program.
BINARY OUTPUT STATUS POINTS
Object Number: 10
Request Function Codes supported: 1 (read)
Default Variation Reported when variation 0 requested: 2 (Binary Output Status)
CONTROL RELAY OUTPUT BLOCKS
Object Number: 12
Request Function Codes supported: 3 (select), 4 (operate), 5 (direct operate), 6 (direct operate, no ack)
BINARY/CONTROL OUTPUT POINTS BINARY/CONTROL OUTPUT POINTS
POINT
IND
EX
NAME/DESCRIPTION POINT
INDEX
NAME/DESCRIPTION
0 OPERATION1 59 VI Self Reset 7-8
1 OPERATION2 60 VI Self Reset 9-10
2 OPERATION3 61 VI Self Reset 11-12
3 OPERATION4 62 VI Self Reset 13-14
4 OPERATION5 63 VI Self Reset 15-16
5 OPERATION6 64 VI Self Reset 17-18
6 OPERATION7 65 VI Self Reset 19-20
7 OPERATION8 66 VI Self Reset 21-22
8 OPERATION9 67 VI Self Reset 23-24
9 OPERATION10 68 VI Self Reset 25-26
10 OPERATION11 69 VI Self Reset 27-28
11 OPERATION12 70 VI Self Reset 29-30
12 OPERATION13 71 VI Self Reset 31-32
13 OPERATION14
14 OPERATION15
15 OPERATION16
16 OPERATION17
17 OPERATION18
18 OPERATION19
19 OPERATION20
20 OPERATION21
21 OPERATION22
22 OPERATION23
23 OPERATION24
24-55 VI latched 1-32
56 VI Self Reset 1-2
57 VI Self Reset 3-4
58 VI Self Reset 5-6
