CHAPTER 7: IEC 61850 PROTOCOL 7.2 IEC 61850 PROFILE FOR F650
GEK-106310-AF F650 DIGITAL BAY CONTROLLER 7-65
7.2.7.3.5 MICS for 650 family of relays whose order code has Rear Ethernet Communication Board 2
option "H", "G", "K", "J", "L", "M" and IEC 61850 Edition 2
Reference documentation: MICS for 650 family rev1.01 firm7_20.
This document describes the:
• Logical Nodes List
• Logical Nodes and Extensions
• Enum types implementation
1 Logical Node List
IEC61850 profile has been updated for F650 firmware version 7.00. The Firmware version 7.00 and above supports IEC
61850 Edition 2. Several Logical Nodes have been added and they have been distributed according its functionality in two
different Logical Devices, one for protection functions and the other for control and measure functions. LGOS (24
instances), PTRC, RBRF, RFLO and CILO (16 instances) have been included. Other Logical Nodes like XSWI and CSWI have
increased their instances to 16 for each one. GGIO nodes and the Logical Nodes for protection functions have suffered
some extensions.
For firmware 7.20 new logical nodes have been included in the data model such as RDRE, RBDR and PTTR. Other logical
nodes like PTOF and PTUF have increased their instances to 6 for each one and suffered some extensions, and CSWI logical
node has also extended its data model.
L: System Logical Nodes
LPHD (Physical device information)
LLN0 (Logical node zero)
LGOS (GOOSE subscription)
GoCB (GOOSE Control Block Class definition)
P: Logical Nodes for protection functions
PIOC (Instantaneous overcurrent)
PTOC (Time overcurrent)
PTOF (Overfrequency)
PTOV (Overvoltage)
PTRC (Protection trip conditioning)
PTTR (Thermal overload)
PTUV (Undervoltage)
PTUF (Underfrequency)
PDOP (Power)**
PFRC (Frequency Rate of Change)**
PDIS (Load Enchroahment)**
PRTR (Locked Rotor)**
R: Logical nodes for protection related functions
RBDR (Disturbance recorder channel binary)
RBRF (Breaker failure)
RDIR (Directional element)
RDRE (Disturbance recorder function)
RFLO (Fault Locator)
RREC (Autoreclosing)
RSYN (Synchrocheck)**
C: Logical Nodes for control
CILO (Interlocking)
CSWI (Switch controller)
