7-64 F650 DIGITAL BAY CONTROLLER GEK-106310-AF
7.2 IEC 61850 PROFILE FOR F650 CHAPTER 7: IEC 61850 PROTOCOL
3.7 PolOpMod
3.8 InMod
3.9 PhLogic
3.10 MaxNumShot
Enum type : PolOpMod
Value Description supported new enum
value added
Value of 650 Relay setting
0 reverse Y Y REVERSE
1 forward Y Y FORWARD
Enum type : InMod
Value Description supported new enum
value added
Value of 650 Relay setting
0 phase-phase Y Y PHASE-PHASE
1 phase-ground Y Y PHASE-GROUND
Enum type : PhLogic
Value Description supported new enum
value added
Value of 650 Relay setting
0 any phase Y Y ANY PHASE
1 two phases Y Y TWO PHASES
2 all phases Y Y ALL PHASES
Enum type : MaxNumShot
Value Description supported new enum
value added
Value of 650 Relay setting
0 1 Shot Y Y 1
1 2 Shots Y Y 2
2 3 Shots Y Y 3
3 4 Shots Y Y 4
